CR2 Series Intelligent Motor Soft Starter

Inquire
  • Brand
    Changshu
  • Series
    CR2
  • Model
    CR2-30
  • Rated Current
    30A
  • Polar Number
    3P
  • Rated Voltage
    400VAC
  • Rated Power
    15KW
  • Rated Control Voltage
    230VAC
  • Usage Category
    AC-53a
  • Set Current
    9-35Ir

Product Details

CR2Series Intelligent Motor Soft Starter Product Parameter Table



Type Frame code Soft starter rated operational current Soft starter setting current Corresponding Ie Controlled motor rated power Rated operational voltage Rated impulse withstand voltage Rated insulation Voltage Us(V)
Rated control power voltage		 Utilization Category Pole
CR2-30 63 30 9～35 15 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-40 63 40 12～46 18.5 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-50 63 50 15～58 22 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-63 63 63 18～73 30 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-75 105 75 22～87 37 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-85 105 85 25～98 45 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-105 105 105 31～121 55 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-142 175 142 40～164 75 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-175 175 175 50～202 90 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-200 175 200 60～230 110 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-250 300 250 75～288 132 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-300 300 300 90～345 160 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53a 3
CR2-340 530 340 102～391 185 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53b 3
CR2-370 530 370 111～426 200 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53b 3
CR2-400 530 400 120～460 220 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53b 3
CR2-450 530 450 135～518 250 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53b 3
CR2-500 700 500 150～575 280 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53b 3
CR2-530 700 530 159～610 300 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53b 3
CR2-570 700 570 171～656 315 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53b 3
CR2-630 700 630 189～725 355 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53b 3
CR2-700 900 700 210～805 400 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53b 3
CR2-800 900 800 240～920 450 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53b 3
CR2-900 900 900 270～1035 500 AC400
50Hz		 8000 800 AC230
50Hz		 AC－53b 3
